dual lane PCB conveyor

Model:HY-460 conveyor

Brand: ASCEN

Delivery Time:15 days

Desciption:

Automatic linking pcb conveyor,SMT conveyor,pcb linking conveyor,500mm/700mm/1000 length PCB link conveyor,SMT linking conveyor,PCB custom conveyor used for equipment linking, visual inspection, manual assembly, and PCB buffering functio

Send Enquiry Download brochure

Product Details

Application:

automatic pcb linking conveyor 1M transfer conveyors are used for equipment linking, visual inspection, manual assembly, and PCB buffering functions. Their advantage is the short length, which allows them to be placed anywhere when you have space limitations.

Description:

1.Elaboration M lead screw, hand width-adjusting system to make 2 conveyor tracks move smoothly.

2.Imported circular special belt and patent tracks, can solve thin card guide PCB problem, improve fluency of connection.

3.Standard signal of industry for equipments, SMEMA can connect with others automatically on line.

4.Machine area made by thickened models or section Aluminum, with superior materials durable service and seed firm.

5.Automatic pcb linking conveyor applicable to production line of SMT and AI, facilitate to connection of equipments before and after.

6.When PCB move interposition during transmitting, it has the function of photo electricity automatic inspection and manual releasing.

7.Increasing weight at the bottom to make machine uneasy to be moved, make connection more smoothly.

Specification

ASCEN team provide a full SMT assembly line solutions,including PCB magazine loader, PCB magazine unloader,Magazine NG ok PCB unloader, multi magazine NG OK pcb unloader,dual magazine PCB loader&unloader,PCB destacker,PCB vacuum loader,PCB vacuum suction loader,PCB stacker,PCB magazine vacuum loader, mini PCB loader,PCB magazine loader L type,dual magazine PCB unloader,magazine PCB NG OK unloader,multi magazine PCB unloader,Lift gate PCB conveyor,PCB flip conveyor, PCB shuttle conveyor, PCB coating conveyor, telescopic gate conveyor,PCB turn conveyor,PCB linking conveyor,NG reject PCB conveyor, PCB inspection conveyor, dual lane PCB conveyor,PCB handling conveyor, PCB custom conveyor,SMT linking conveyor,PCB belt conveyor are available as standard and customized products and can be equipped to fit special requirements

Please collecting our web:www.ascen.ltd , we will updated more solution for help your assembly line to save more cost.

Item	Scope of application
Model number: (linking conveyor type)	HY-460 conveyor
Dimensions(LWH)	600(length optional )750900mm
PCB Width	50-400mm
Conveyor Height	900+/-20mm
PCB Direction	L-R(R-L)
Speed	0~1500(mm)/Min
Power Consumption	0.5KW
Power Supply	1P AC220V 50/60HZ
Guide-rail Length	0.6-2M(or as requirement)
Control System	0.6-2M(or as requirement)
Control method	Press key+PLC
Foot switch	Standard
Lighting	Option
SOP Rack	Option
Platform Material	ESD Rubber Mat
Communication Plug	SMEMA Signal Plug for up/down line Double-wire cable
